API 682 – Plan 23

The Flopac SPX series include Plan 23 seal flushing units, typically used with arrangement 1 contacting wet seals (1CW-FX, 1CW-FL), or with arrangement 2 seals (2CW-CW) in combination with Plan 52. Plan 23 circulates the seal chamber liquid through a seal cooler in a closed loop, cooling and lubricating the (inner) seal and reducing the product vapour pressure at the seal chamber. Built in-house to API 682 specifications.

Advantages

Plan 23 – Solution

For a completely packaged API 682 compliant system.

Just need an API 682 cooler and prefer to do your own packaging?
